Powder weighing system
Precise weighing of even multiple types of powder
This system uses AI technology to weigh multiple powder materials. It recognizes the shapes of powder piles, and can weigh specified amounts and prepare samples. It automates tasks that are difficult to verbalize, ensuring consistent precision and reproducibility.
Operation overview
-
01
Container removal and cap opening
Up to 10 containers can be placed on the supply and discharge trays, allowing for up to 10 types of samples to be weighed.
-
02
Sample container removal and cap opening.
Container QR codes are scanned to acquire traceability information. Caps are opened only when required, preventing sample volatilization and contamination.
-
03
Scooping using AI
AI determines the state of the powder and operates the dispensing spoon at the optimal insertion level. The ionizer removes static electricity while scooping.
-
04
Weighing out into empty container
The system mirrors the movements of an expert worker when sieving powder, in order to adjust the weighing value. The scale with draft protection cover automatically opens and closes, allowing for highly precise measurement.
System specifications
| Maximum weighing | 320 g |
| Weighing precision | Roughly 5 g ±10% *varies by type of powder |
| System dimensions | Approx. 1,000 mm (W) × 650 mm (D) × 550 mm (H) |
| Weight | Approx. 45 kg |
| Power supply | Single-phase 100 VAC 15 A |
Available containers
-
PP bottles
50 ml, 100 ml
-
Screw-top bottles
50 ml, 100 ml
-
Beakers
50 ml, 100 ml
System usage parts
-
Electronic scale
A&D AD-4212C
| Specifications | |
|---|---|
| Weighing | 320 g |
| Minimum display | 0.001 g |
| Protection grade | IP65 |
-
Powder weighing skill (AI)
AI is used to automate tasks consisting of movements difficult to reproduce through programming, such as tasks where the powder shape varies depending on the scooping position and depth.
*Specifications may be changed.
