Keyboard interface software which can convert scanner input into keyboard data

  • Feature
  • Operation Environment

Data conversion to translate RS-232C input into keyboard data

QRkbif can convert the data received from RS-232C port and pass it to an application program in such a manner that the application thinks the data is actually entered from the keyboard. Data transmission is supported in either Text or Keyboard mode. The terminal emulation software is also supported.

Data transmission to a target window

Data is generally transmitted to an active window (the foremost window). However, given user's specification, QRkbif can send to the target window even if it is currently inactive or minimized, resulting in fewer input errors and missing data.

Multiple QR_kbif operations in N-to-one and N-to-N connections

Not only a single scanner (one-to-one connection), the application can also support several scanners (N-to-one). In addition, if multiple QR_kbif are concurrently operated and target window is specified, more complex topologies such as N-to-N, N-to-M (M>N) can be established.

Advanced data editing

Thanks to ADF script support, QRkbif can manage any string operations including conditional judgment, scanner control, and external program execution.

Simple editing menu

Add the data edit function to enable any strings to add/delete before or after the data.


QRkbif can display the incoming RS-232C data in both ASDII/JIS code and hexadecimal numeric simultaneously, providing thorough information of transmitted data including those characters otherwise explicitly unidentified.

Operation Environment

OS Windows® Vista(32bit), Windows® 7(32bit/64bit[WOW64]), Windows® 8(32bit/64bit[WOW64]), Windows® 8.1(32bit/64bit[WOW64]), Windows® 10(32bit/64bit(WOW64))(1)(3)
CPU Celeron 1GHz or higher (recommended)(2)
Memory Minimum 512MB for Windows® XP (1), or minimum 1GB for other OS
Disk space Minimum 6MB free hard disk space

Supported Scanners

Model Type
AT Series All model
GT Seties All model
HC56 Series All model
QB Series All model
QD25 Series All model
QK12 Series All model
QK20 Series All model
QK30 Series All model
QS20P Series QS20P-A11
SE1 Series All model
  1. 1.Microsoft® and Windows® are either registered trademarks or trademarks of Microsoft Corporation in the United States and other countries.
  2. 2.Celeron® is a registered trademark of Intel Corporation in the US and other countries.
  3. 3.This application is executed as Win32 application on Windows 7(64 bits) and Windows 8(64bits) using WOW64 (Windows 32-bit emulation on Windows 64-bit).
