  • Feature
  • Operation Environment

Monitor the Running State of a Program on a BHT(1)

Single line stepwise execution can be performed, and breakpoints to monitor running state can be set. Easy debugging of programs can be achieved by checking the value of variables and the state of the stack.

Manage Multiple Applications Together

Managing multiple application programs as one workspace can be achieved, allowing collective debugging, even when switching between different application programs.

High Speed Transfer of Application Programs

There is a feature that compresses a BHT application program to transfer at high speed, allowing fast upload of debugged programs.

Build Program

Launch the BHT-BASIC compiler (sold separately) to compile/build a BHT-BASIC source program.

  1. 1.The communication area (an optical communication port and connector) in the application program cannot be debugged as communication with the BHT while debugging is ongoing. Debugging of wireless communication can be achieved since it has a separate port.

Operation Environment

Model supported PC/AT compatible
OS supported Windows®2000/XP, Windows Vista (32bit Ver.)(1)
CPU CPU with Intel®architecture
Memory Memory required for normal operation of the above OS
HDD 5 MB of free space or more
Serial port Serial port supporting communication speed of 115200 bps
Display Resolution of 800 x 600 dots or higher
BHT Supported
Operation Mode Model requirement of System version(2)
BHT-BASIC4.0 BHT-300 Series All version
BHT-BASIC3.6 compatible BHT-7000 Ver. 2.03 or above
BHT-7500 Ver. 1.26 or above
BHT-7500W Ver. 1.04 or above
BHT-8000 Ver. 1.02 or above
BHT-8000D Ver. 1.03 or above
BHT-103Q Ver. 2.02 or above
BHT-102B Ver. 2.03 or above
BHT-100BW All versions
BHT-100QW All versions
  1. 1.Microsoft®and Windows® are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Pentium® is a registered trademark or trademark of Intel Corporation in the U.S. and other countries.
  2. 2.The latest system can be downloaded from QBdirect (only for Registered Users )
